Codan NGT 2012 RF User Manual

08-05235-002
04 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Oven, Hi-Stab for HC18 Xtal 08-05235 1
Oven, Crystal 04-03095 1
H/Stab. Crystal Oven 11-05235 1
1 PCB, Oven, Crystal Codan 07-01732-04 07-01732-04 1
2 Heatsink, Oven Metalcraft 05-06936 05-06936 1
3 Tape, Masking 13mm
33m
Permacel P-221 (Paint Mask) 30-39306-006 1
C1 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C2 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
IC1 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
R1 820 Ohm 5% 0,125W 1206 Philips 2322 711 61821 40-28200-101 1
R2 2,2k Ohm 5% 0,125W 1206 Philips 2322 711 61222 40-32200-101 1
R3 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R4 30k Ohm 5% NTC
Thermistor
Philips 2322 633 53303 41-04303-000 1
R5 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R6 270 Ohm 5% 0,125W 1206 Philips 2322 711 61271 40-22700-101 1
R7 150 Ohm 5% 0,125W 1206 Philips 2322 711 61151 40-21500-101 1
R8 100k Ohm 5% 0,06W 0603 Philips 2322 702 60104 40-51000-121 1
R9 100k Ohm 5% 0,06W 0603 Philips 2322 702 60104 40-51000-121 1
R10 1M Ohm 5% 0,125W 1206 Philips 2322 711 61105 40-61000-101 1
R11 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R12 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R13 3,3 Ohm 5% 0,125W 1206 Philips 2322 711 61338 40-03300-101 1
R14 3,3 Ohm 5% 0,125W 1206 Philips 2322 711 61338 40-03300-101 1
V1 Diode, Zener 6,8V 5% 0,2W
SOT23
Philips BZX84C6V8 BZX84C6V8 1
V2 MOSFET, Power N Channel Motorola MTD3055EL1 MTD3055EL1 1
V3 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Z401 Crystal, 44545 kHz series HY-Q TW07S QC49 65-90102 1
08-05235-002 - Oven, Hi-Stab for HC18 Xtal
BOM Revision
Date Valid On
Page 1 of 1
