08-05995-001
01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
Backplane 04-02691 1
PCB, Backplane Codan 07-01348-03 07-01348-03 1
* Backplane PCB 08-05995 1
2 Card Frame-Rear Plate Metalcraft 08-04131 08-04131 2
3 Nut, M2,5 MS Zn Pl Hex Spec 01-00201 31-22500-001 31-22500-001 8
4 Screw, M2,5x6 304 SS Pan
Pozi
James Glen 31-22506-580 31-22506-580 8
5 Nut, M3 MS Zn Pl Hex Spec 01-00201 31-23000-001 31-23000-001 2
6 Screw, M3x8 304 SS Pan Pozi * 31-23008-580 31-23008-580 2
7 Jumper (S) 2way Open Top Molex 15-38-1024 60-90410-001 6
8 Stake, Terminal Autosplice 7-22461-5 61-40300-004 6
C1 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C2 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C3 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C4 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C5 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C6 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C7 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C8 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C9 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C10 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C11 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C12 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C13 100n 20% 50V X7R CE
Cap
Vitramon VP41BY104MA 46-51000-261 1
C14 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
C15 100n 20% 50V X7R CE
Cap
Vitramon VP41BY104MA 46-51000-261 1
C16 2,2u 20% 35V TA Cap AVX TAP225M035CCS 47-02203-510 1
C101 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C102 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C103 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C104 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C301 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C302 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C303 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
08-05995-001 - Backplane PCB
BOM Revision
Date Valid On
Page 1 of 3
