Codan NGT 2012 RF User Manual

10 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03993 - MicroP & Tcvr I/F PCB
BOM Revision
Date Valid On
R47 3,3k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X332M 40-83330-500 1
R48 100k Ohm 2% 0,4W MF
Res
Philips 2322 181 54104 40-51000-500 1
R49 100k Ohm 2% 0,4W MF
Res
Philips 2322 181 54104 40-51000-500 1
R50 220 Ohm 5% 0,33W CF
Res
Philips 2322 211 13221 40-22200-020 1
S1 Switch, Binary 16 Position Copal S1030 62-61623-001 1
T1 Txfr Protran 44-30821 44-30821 1
T2 Txfr Protran 44-30821 44-30821 1
V1 Transistor, NPN Si Philips BC548 BC548 1
V2 Transistor, NPN Si Philips BC548 BC548 1
V3 Transistor, NPN Si Philips BC548 BC548 1
V4 Transistor, NPN Si Philips BC548 BC548 1
V5 Diode, Ref 5,0V 2% IC National Semiconduct LM336Z-5.0 XB-00336-505 1
Z1 Crystal, 3579,545 kHz uP
Grade
HY-Q M/P QC49 3579,545KHZ 65-90060-000 1
Z2 Crystal, 12000 kHz uP
Grade
HY-Q M/P QC49 12000KHZ 65-90014-000 1
Page 5 of 5

Codan NGT 2012 RF Specifications

General

Brand	Codan
Model	NGT 2012 RF
Category	Transceiver
Language	English
