Codan NGT 2012 RF User Manual

10 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03993 - MicroP & Tcvr I/F PCB
BOM Revision
Date Valid On
R17 9,1k Ohm 2% 0,4W MF
Res
Philips 2322 181 54912 40-39100-500 1
R18 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R19 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R20 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R21 1k Ohm 5% 0,33W CF
Res
Philips 2322 211 13102 40-31000-020 1
R22 Not Fitted Codan **-00000-001 99-00000-001 1
R23 100 Ohm 5% 0,33W CF
Res
Philips 2322 211 13101 40-21000-020 1
R24 56k Ohm 5% 0,33W CF
Res
Philips 2322 211 13563 40-45600-020 1
R25 27k Ohm 5% 0,33W CF
Res
Philips 2322 211 13273 40-42700-020 1
R26 33k Ohm 5% 0,33W CF
Res
Philips 2322 211 13333 40-43300-020 1
R27 33k Ohm 5% 0,33W CF
Res
Philips 2322 211 13333 40-43300-020 1
R28 4,7k Ohm 5% 0,33W CF
Res
Philips 2322 211 13472 40-34700-020 1
R29 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R30 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R31 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R32 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R33 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R34 2,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13222 40-32200-020 1
R35 2,2k Ohm 5% 0,33W CF
Res
Philips 2322 211 13222 40-32200-020 1
R36 2,7k Ohm 2% 0,4W MF
Res
Philips 2322 181 54272 40-32700-500 1
R37 Temperature Sensor 1000
Ohm 1%
Philips KTY81-110 KTY81-110 1
R38 15k Ohm 2% 0,4W MF
Res
Philips 2322 181 54153 40-41500-500 1
R39 2,7k Ohm 2% 0,4W MF
Res
Philips 2322 181 54272 40-32700-500 1
R40 100k Ohm 5% 0,33W CF
Res
Philips 2322 211 13104 40-51000-020 1
R41 33k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X333M 40-84330-500 1
R42 1,5k Ohm 5% 0,33W CF
Res
Philips 2322 211 13152 40-31500-020 1
R44 4,7k Ohm 5% 0,33W CF
Res
Philips 2322 211 13472 40-34700-020 1
R45 4,7k Ohm 5% 0,33W CF
Res
Philips 2322 211 13472 40-34700-020 1
R46 33k Ohm 20% 0,1W SIL
Com x5Res
Murata RGSD5X333M 40-84330-500 1
Page 4 of 5
