Codan NGT 2012 RF User Manual

10 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-03993 - MicroP & Tcvr I/F PCB
BOM Revision
Date Valid On
IC5 Buffer, Hex Inverting Schmitt IC Motorola MC74HC14N YH-74014-000 1
IC6 Modem, 300 baud, Bell 103
IC
National Semiconduct MM74HC943N YH-74943-000 1
IC7 Compander, Audio IC Signetics NE571N XA-00571-000 1
IC8 EEPROM, CMOS 256 x 8 Bit
IIC Bus
Philips PCF8582AP YM-08582-000 1
IC9 Supervisory, Pwr&reset 4.75V
IC
Philips PCF1252-OP XD-01252-100 1
IC10 Reg, Voltage +10V IC National Semiconduct LM2940T-10 XB-02940-402 1
IC11 Array, Transistor IC Motorola MC1413P XT-01413-000 1
IC12 MCU, 8bit 16MHz
PLCC68
Philips PCB80C552-5-16WP YP-80552-900 1
IC13 Latch, Octal IC Motorola MC74HC573N YH-74573-000 1
IC14 EPROM, prgmd NGT 8571 Codan 90-20613-001 90-20613-001 1
IC15 RAM, CMOS 8k x 8 Bit IC Hitachi HM6264P-15 YM-06264-000 1
IC16 Timer, Programmable CMOS
IC
OKI Semi Cond MSM82C53-2RS YL-08253-001 1
IC17 Filter, Switched Cap LP IC National Semiconduct MF4CN-100 MF4CN-100 1
L1 Ind, 1mH 5% Taiyo Yuden LHL06 NB 102J 43-83100-097 1
L2 Ind, 1mH 5% Taiyo Yuden LHL06 NB 102J 43-83100-097 1
P1 Connector, 64way Male 90 deg
PCB
ITT-Cannon G06D064P4BEBL 60-51100-064 1
R1 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R2 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R3 15k Ohm 5% 0,33W CF
Res
Philips 2322 211 13153 40-41500-020 1
R4 4,7k Ohm 2% 0,4W MF
Res
Philips 2322 181 54472 40-34700-500 1
R5 5,6k Ohm 2% 0,4W MF
Res
Philips 2322 181 54562 40-35600-500 1
R6 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R7 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R8 11,0k Ohm 1% 0,4W MF
Res
Philips 2322 156 11103 40-41100-501 1
R9 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R10 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R11 470 Ohm 5% 0,33W CF
Res
Philips 2322 211 13471 40-24700-020 1
R12 10k Ohm 5% 0,33W CF
Res
Philips 2322 211 13103 40-41000-020 1
R13 5,6k Ohm 2% 0,4W MF
Res
Philips 2322 181 54562 40-35600-500 1
R14 39k Ohm 2% 0,4W MF
Res
Philips 2322 181 54393 40-43900-500 1
R15 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
R16 10k Ohm 2% 0,4W MF
Res
Philips 2322 181 54103 40-41000-500 1
