10 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-03993 - MicroP & Tcvr I/F PCB
BOM Revision
Date Valid On
C22 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C23 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C24 47u 16V Ax EL Cap Jamicon SKR470T1CE11 48-14701-651 1
C25 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C26 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C27 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C28 3,3n 10% 100V CE Cap Philips 2222 630 03332 46-33300-200 1
C29 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C30 100n 10% 63V PE Cap Philips 2222 370 11104 46-51000-521 1
C31 10u 20% 25V TA Cap AVX TAP106M025CCS 47-11002-510 1
C32 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C33 22p 2% 100V NPO CE
Cap
Philips 2222 680 10229 46-12200-011 1
C34 22p 2% 100V NPO CE
Cap
Philips 2222 680 10229 46-12200-011 1
C35 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C36 3,3n 10% 100V CE Cap Philips 2222 630 03332 46-33300-200 1
C37 1u 20% 35V TA Cap AVX TAP105M035CCS 47-01003-510 1
C38 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C39 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C40 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C41 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C42 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C43 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C44 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C45 220p 2% 100V N750 CE
Cap
Philips 2222 680 58221 46-22200-013 1
D1 Diode, Si small sig GP Codan 23-10005 23-10005 1
H1 LED, Red T-1 Diffused Liteon LTL-4221 65-61110-209 1
IC1 Buffer, Hex Inverting Schmitt IC Motorola MC74HC14N YH-74014-000 1
IC2 MUX/DEMUX, Analog Triple 2
Ch IC
National Semiconduct CD4053BCN YG-40053-000 1
IC3 Amp, Operational Dual IC National Semiconduct LM358N XA-00358-100 1
IC4 Filter,Switched Cap IC National Semiconduct MF10CCN MF10CCN 1
Page 2 of 5
