High power—Technical description

NGT Transceiver System Technical Service Manual 227

3061/3062 power amplifiers

Supply voltages

The supply voltages for the power amplifiers are shown in Table 9, Table 10, and

Table 11.

Drawing 04-03418 (sheet 1) and 04-03418 (sheet 2)

Table 9: Supply voltages for the Control PCB in the power amplifier

Supply Description Source

+5 V +5 V analog and digital supply IC101

+13V6 13.6 V unregulated supply from NGT RF unit

Drawing 04-03416

Table 10: Supply voltages for the Power Amplifier PCB in the power amplifier

Supply Description Source

+5 V_BIAS +5 V bias supply from Power Supply PCB

PA+ Variable regulated supply from Power Supply PCB

Drawing 04-03417

Table 11: Supply voltages for the Power Supply PCB in the power amplifier

Supply Description Source

+5 VREF +5 V reference supply IC1

+13V6 13.6 V unregulated supply via Control PCB

PWR_IN +70 V regulated supply from power supply unit
