Codan NGT 2012 RF User Manual

01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05995-001 - Backplane PCB
BOM Revision
Date Valid On
C304 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C305 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C306 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C307 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C308 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C309 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C310 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C311 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C312 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C313 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C314 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
C315 1n 10% 100V CE Cap Vishay 2222 326 03102 46-31000-200 1
D1 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
D2 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
D3 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
D4 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
IC1 Reg, Voltage +5V 1,5A IC National Semiconduct LM340T-5 XB-07805-400 1
IC2 Reg, Voltage +15V 1,5A IC National Semiconduct LM340T-15 XB-07815-400 1
J1 Connector, 64way Fem Solder
PCB
ITT-Cannon G06D064P3BBBL 60-51201-064 1
J2 Connector, 64way Fem Solder
PCB
ITT-Cannon G06D064P3BBBL 60-51201-064 1
J101 Connector, 64way Fem Solder
PCB
ITT-Cannon G06D064P3BBBL 60-51201-064 1
J301 Connector, 64way Fem Solder
PCB
ITT-Cannon G06D064P3BBBL 60-51201-064 1
L301 Ind, 1mH 10% Taiyo Yuden FL 5H 102K 43-83100-095 1
P1 Header (P) 16way 2row thin
insul
Berg 67997-416H 60-00160-001 1
P2 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
P3 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
P4 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
P5 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
P6 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
P7 Header (P) 4way 1row Latch JAE IL-4P-S3EN2 60-00040-261 1
P101 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
P102 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
P103 Header (P) 8way 1row Molex 22-03-2081 60-00081-100 1
P104 Header (P) 2way 1row Latch JAE IL-2P-S3EN2 60-00020-260 1
P105 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
P301 Header (P) 16way 2row JAE PS-16PE-D4T1-PN1 60-00160-260 1
P302 Header (P) 10way 2row JAE PS-10PE-D4T1-PN1 60-00100-260 1
P303 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
P304 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
P305 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
P306 Header (P) 3way 1row Molex 22-03-2031 60-00031-100 1
Page 2 of 3

Codan NGT 2012 RF Specifications

General

Brand	Codan
Model	NGT 2012 RF
Category	Transceiver
Language	English
