Codan NGT 2012 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06461-001 - PA c/w Heatsink PCB
BOM Revision
Date Valid On
R281 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R282 Not Fitted Codan **-00000-001 99-00000-001 1
T200 Transformer, Input Protran 44-80283 44-80283 1
T201 Transformer, Pre-driver I/P Protran 44-80284 44-80284 1
T202 Transformer, Pre-Driver Codan 44-80318 44-80318 1
T203 Driver Transformer Protran 44-80279 44-80279 1
T204 Output Transformer Protran 44-80277 44-80277 1
V200 Transistor, NPN Si 18V 0,15A
4GHz SOT89
Philips BFQ18A BFQ18A 1
V201 Transistor, NPN Si 18V 0,15A
4GHz SOT89
Philips BFQ18A BFQ18A 1
V202 JFET, N Channel SOT23 Philips PMBFJ309-215 PMBFJ309 1
V203 JFET, N Channel SOT23 Philips PMBFJ309-215 PMBFJ309 1
V204 Transistor, NPN Si 40V 600mA
1,1W SOT89
Philips PXT4401 PXT4401 1
V205 Transistor, NPN Si 40V 600mA
1,1W SOT89
Philips PXT4401 PXT4401 1
V207 FET, RF Power, 6W Mitsubishi RD06HVF1-101 RD06HVF1 1
V208 FET, RF Power, 6W Mitsubishi RD06HVF1-101 RD06HVF1 1
V209 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V210 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V211 Transistor, RF Power HF Microsemi MS1253-CDN MS1253-CDN 1
V212 Transistor, RF Power HF Microsemi MS1253-CDN MS1253-CDN 1
V213 Transistor, Darlington NPN Si Philips BD675 BD675 1
V215 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V216 Transistor, PNP Si SOT23 Philips BC856 BC856 1
V217 Transistor, PNP Si SOT89 Philips BC869 BC869 1
Page 6 of 6
