Codan NGT 2012 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06461-001 - PA c/w Heatsink PCB
BOM Revision
Date Valid On
R249 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R250 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R251 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R252 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R253 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R254 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R255 470 Ohm 5% 0,1W 0805 Philips 2322 730 61471 40-24700-111 1
R256 180k Ohm 1% 0,1W 0805 Philips 2322 734 61804 40-51800-115 1
R258 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R259 3,3 Ohm 5% 0,1W 0805 Philips 2322 730 61338 40-03300-111 1
R260 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R261 Res, Voltage Dependent Philips 2322-592-52506 41-22506-592 1
R262 50 Ohm 80'C PTC
Thermistor
Philips 2322-660-91008 41-11500-660 1
R263 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R264 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R265 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R266 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R267 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R268 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R269 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R270 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R271 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R272 560 Ohm 5% 0,1W 0805 Philips 2322 730 61561 40-25600-111 1
R273 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R274 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R275 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R276 Not Fitted Codan **-00000-001 99-00000-001 1
R277 3,3 Ohm 5% 0,1W 0805 Philips 2322 730 61338 40-03300-111 1
R278 Not Fitted Codan **-00000-001 99-00000-001 1
R279 Not Fitted Codan **-00000-001 99-00000-001 1
R280 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
