Codan NGT 2012 RF User Manual

07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05988-001 - Audio & Interconnect PCB
BOM Revision
Date Valid On
R103 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R104 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R105 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R106 1,8k Ohm 5% 0,1W 0805 Philips 2322 730 61182 40-31800-111 1
R107 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R108 220k Ohm 5% 0,1W 0805 Philips 2322 730 61224 40-52200-111 1
R109 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R110 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R111 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R112 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R113 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R114 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R115 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R116 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
V1 Transistor, PNP Si SOT23 Philips BC857 BC857 1
V2 Diode, Zener 6,8V 5% 0,2W
SOT23
Philips BZX84C6V8 BZX84C6V8 1
V3 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V4 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V5 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V6 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V7 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V8 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V9 Transistor, PNP Si SOT23 Philips BC857 BC857 1
V10 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V11 Transistor, NPN Si SOT23 Philips BC847 BC847 1
Z1 Crystal 4MHz Up Grade
SMD
HY-Q QC49/SMD EB01C 65-90109 1
Z2 Crystal, 32,768kHz 12pF HY-Q TC38 65-90057-000 1
Page 9 of 9
