Codan NGT 2012 RF User Manual

04 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05926-001 - High Pwr PA & Ant Controller
BOM Revision
Date Valid On
R44 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R45 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R46 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
S1 Switch, Binary 16 Position Copal S1030 62-61623-001 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V2 Diode, Schottky SOT23 Philips BAT54 BAT54 1
V3 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V4 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V5 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V6 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V7 MOSFET, Power N channel
TO252
Motorola MTD3055EL MTD3055EL 1
V8 Transistor, NPN Si SOT23 Philips BC848 BC848 1
Page 5 of 5
