Codan NGT 2012 RF User Manual

02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06260-001 - Appn Proc PCB, Handset & Data I/F
BOM Revision
Date Valid On
R87 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R88 120 Ohm 5% 0,06W 0603 Philips 2322 702 60121 40-21200-121 1
R89 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R90 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R91 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R92 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
V1 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V2 MOSFET, Power N Channel
TO252
Motorola MTD3055V MTD3055V 1
Z1 Crystal, 11059,2 kHz uP
Grade
HY-Q M/P QC49/SMD EB01C 65-90094 1
Page 8 of 8
