Codan NGT 2012 RF User Manual

10 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05869-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
R248 47 Ohm 5% 0,1W 0805 Philips 2322 730 61479 40-14700-111 1
R249 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R250 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R251 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R252 2,2 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-2R20-J-7 40-02200-135 1
R253 470 Ohm 5% 0,1W 0805 Philips 2322 730 61471 40-24700-111 1
R254 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R255 470 Ohm 5% 0,1W 0805 Philips 2322 730 61471 40-24700-111 1
R256 180k Ohm 1% 0,1W 0805 Philips 2322 734 61804 40-51800-115 1
R258 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R259 4,7 Ohm 5% 0,1W 0805 Phycomp 2322 730 61478 40-04700-111 1
R260 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R261 Res, Voltage Dependent Philips 2322-592-52506 41-22506-592 1
R262 50 Ohm 80'C PTC
Thermistor
Philips 2322-660-91008 41-11500-660 1
R263 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R264 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R265 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R266 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R267 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R268 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R269 4,7 Ohm 5% 1,0W 2512
MELF
IRC CHP1-100-4R70-J-7 40-04700-135 1
R270 47 Ohm 5% 0,1W 0805 Philips 2322 730 61479 40-14700-111 1
R271 68 Ohm 5% 0,1W 0805 Philips 2322 730 61689 40-16800-111 1
R272 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R273 Pot,100 Lin MG Trim SMD Bourns 3314 J-1-101 42-21004-000 1
R274 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R275 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R276 Not Fitted Codan **-00000-001 99-00000-001 1
T200 Transformer, Input Protran 44-80283 44-80283 1
T201 Transformer, Pre-driver I/P Protran 44-80284 44-80284 1
T202 Pre-Driver Transformer Protran 44-80278 44-80278 1
T203 Driver Transformer Protran 44-80279 44-80279 1
Page 5 of 6
