09 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05300-001 - Handset PCB
BOM Revision
Date Valid On
C26 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C27 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C28 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C29 1u 20% 35V 3528 TA
Cap
AVX TAJB105M035R 47-01003-520 1
C30 220p 5% 50V NPO 0805
NiSn
Philips 0805CG221J9BB 46-22200-081 1
C31 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
H1 Display, 98x32 dot LCD back-
lit
Powertip PG9832LRS-ANN-H-Y1 65-63000 1
IC1 MCU, 8 Bit CMOS 30MHz 8Kb
32I/O PLCC44
Atmel TS80C32X2-MCB-R YP-08032-900 1
IC2 Monitor, Micro
SOIC8
Dallas DS1232LPS-2 XD-01232-700 1
IC3 PSD prgmd, Handset Codan 90-20597-001 90-20597-001 1
IC4 Buffer, Hex Inverting Schmitt
SOIC14
Motorola MC74HC14D YH-74014-700 1
IC5 Tcvr, RS232 DUAL +12V
SOIC16
Maxim MAX231CWE YI-00231-700 1
IC6 Pot, 1k Digital
SOIC8
Xicor X9313ZS YN-09313-700 1
IC7 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC8 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC9 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC10 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
J1 Socket, Jack 3,5 dia stereo
PCB
Marushin MJ-156L 60-00013-373 1
L1 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L2 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L3 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L4 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P1 Header (P) 4way 1row 2mm
Fixed
Samtec TW-04-09-L-S-120-150 60-00040-000 1
P2 Header (P) 5way 1row 2mm
Fixed
Samtec TW-05-09-L-S-120-150 60-00050-000 1
P3 Header (P) 5way 1row 2mm
Fixed
Samtec TW-05-09-L-S-120-150 60-00050-000 1
Page 2 of 5
