Codan NGT 2012 RF User Manual

09 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05300-001 - Handset PCB
BOM Revision
Date Valid On
R54 100k Ohm 1% 0,1W 0805 Philips 2311 734 61004 40-51000-115 1
R55 220 Ohm 1% 0,1W 0805 Philips 2322 734 62201 40-22200-115 1
V1 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V2 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V3 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V4 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V5 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
V6 Transistor, PNP Si SOT89 Philips BC869 BC869 1
V7 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V8 Diode, Zener 6,8V 5% 0,2W
SOT23
Philips BZX84C6V8 BZX84C6V8 1
V9 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
Z1 Crystal, 14745,6 kHz uP
Grade
HY-Q QC49/SMD 14745,6KHZ 65-90104 1
Page 5 of 5
