07 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05470-001 - Audio PCB
BOM Revision
Date Valid On
R60 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R61 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R62 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R63 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R64 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R65 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R66 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R67 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R68 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R69 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R70 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R71 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R72 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R73 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R74 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R75 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R76 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R77 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R78 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R79 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R80 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R81 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R82 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R83 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R84 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R85 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R86 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
T1 Txfr, Line isolation SMD Etal P2781 43-30002 1
V1 Transistor, NPN Si SOT23 Philips BFR92A BFR92A 1
Page 7 of 8
