Codan NGT 2012 RF User Manual

05 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05986-001 - Audio PCB
BOM Revision
Date Valid On
C57 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C58 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C59 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C60 100n 10% 50V X7R 0805
Nisn
Philips 08052R104K9BB 46-51000-282 1
C61 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C62 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C63 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C64 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C65 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C66 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C67 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C68 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C69 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C70 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C71 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C72 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C73 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C74 3,3n 10% 100V X7R 0603
NiSn
Vishay VJ0603Y332KXBAC 46-33300-282 1
C75 220p 5% 50V NPO 0603
NiSn
Philips 0603CG221C9BB00 46-22200-083 1
C76 220p 5% 50V NPO 0603
NiSn
Philips 0603CG221C9BB00 46-22200-083 1
C77 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
C78 22p 5% 100V NPO 0603
NiSn
Philips 0603CG220J0B200 46-12200-083 1
C79 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C80 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
C81 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, 400V 1A SMA On Semiconductor MRA4004T3 MRA4004T3 1
H1 LED, Tricolour T-1 3/4
Diffused
Liteon LTL-52RG 65-61110-901 1
