15 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05317-001 - MicroP PCB
BOM Revision
Date Valid On
C25 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C26 1u 10% 16V X7R 1206
NiSn
Philips 12062R105K7BB00 46-61000-280 1
D1 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D4 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
H1 Not Fitted Codan **-00000-001 99-00000-001 1
H2 Not Fitted Codan **-00000-001 99-00000-001 1
H3 Not Fitted Codan **-00000-001 99-00000-001 1
H4 Not Fitted Codan **-00000-001 99-00000-001 1
IC1 MicroC, 16 Bit CMOS
QFP20112
Hitachi HD6413003TF16 YP-83003-700 1
IC2 Monitor, Micro
SOIC8
Dallas DS1232LPS-2 XD-01232-700 1
IC3 Serial Number, 48 bit
SOT223
Dallas DS2401Z YM-02401-700 1
IC4 FLASH prgmd, Junction Box Braemac 90-20596-001 90-20596-001 1
IC5 Gate, AND 2 Input Quad
SOIC14
Motorola MC74HC08AD YH-74008-700 1
IC7 Buffer, Hex inverting schmitt
SOIC14
Motorola MC74AC14D YS-74014-700 1
IC8 SRAM, CMOS 256k x 16 Bit
20ns SOJ44
Alliance AS7C4098-20JC YM-74098-700 1
IC9 DTMF Tone Generator
SOIC8
Philips PCD3312CT-118 XE-03312-700 1
IC10 DUART, CMOS
PLCC44
Philips SC26C92C1A YK-02692-900 1
IC11 Cntlr, CAN bus 2,0B
SOIC28
Philips SJA1000T/N1 YL-81000-700 1
IC12 Tcvr, RS232 6Tx / 10Rx ESD
PROT TSSOP38
Maxim MAX3209ECUU YI-03209-700 1
IC13 Reg, Voltage +5V 1A
TO263_3
National Semiconduct LM7805S XB-07805-701 1
IC14 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC15 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC16 FLASH, Serial 512k x 8 Bit 3V
SOIC8
Atmel AT45DB041B-SC YM-45041-700 1
P1 Not Fitted Codan **-00000-001 99-00000-001 1
P3 Not Fitted Codan **-00000-001 99-00000-001 1
R1 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R2 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R3 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R4 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R6 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R7 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
Page 2 of 4
