Codan NGT 2012 RF User Manual

15 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05317-001 - MicroP PCB
BOM Revision
Date Valid On
R38 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R39 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R40 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R41 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R42 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R43 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R44 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R45 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R46 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R47 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R48 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R49 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R50 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R51 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R52 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V2 Diode, Zener 3,3V 5% 0,2W
SOT23
Philips BZX84-C3V3 BZX84C3V3 1
V3 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V4 Diode, Zener 12V 5% 0,2W
SOT23
Philips BZX84-C12 BZX84C12 1
Z1 Crystal, 16000 kHz uP
Grade
HY-Q QC49/SMD 65-90103 1
Z2 Crystal, 3686,4 kHz uP
Grade
HY-Q M/P QC49/SMD EBO1C 65-90101 1
Page 4 of 4
