Codan NGT 2012 RF User Manual

12 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05261-001 - RF/IF PCB
BOM Revision
Date Valid On
R271 3,3k Ohm 5% 0,125W 1206 Philips 2322 711 61332 40-33300-101 1
R272 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R273 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R274 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R275 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R276 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R277 1k Ohm 5% 0,125W 1206 Philips 2322 711 61102 40-31000-101 1
R278 0 Ohm Jumper 1206 Philips 2322 711 90001 40-00001-101 1
R279 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R280 220k Ohm 5% 0,125W 1206 Philips 2322 711 61224 40-52200-101 1
R281 22k Ohm 5% 0,125W 1206 Philips 2322 711 61223 40-42200-101 1
R282 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R283 1M Ohm 5% 0,125W 1206 Philips 2322 711 61105 40-61000-101 1
R284 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R285 47k Ohm 5% 0,125W 1206 Philips 2322 711 61473 40-44700-101 1
R286 1M Ohm 5% 0,125W 1206 Philips 2322 711 61105 40-61000-101 1
R287 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R288 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R289 8,2k Ohm 5% 0,125W 1206 Philips 2322 711 61822 40-38200-101 1
R290 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R291 1,2k Ohm 5% 0,125W 1206 Philips 2322 711 61122 40-31200-101 1
R292 1,8k Ohm 5% 0,125W 1206 Philips 2322 711 61182 40-31800-101 1
R293 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R294 18k Ohm 5% 0,125W 1206 Philips 2322 711 61183 40-41800-101 1
R295 100k Ohm 5% 0,125W 1206 Philips 2322 711 61104 40-51000-101 1
R296 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R297 10k Ohm 5% 0,125W 1206 Philips 2322 711 61103 40-41000-101 1
R298 4,7k Ohm 5% 0,125W 1206 Philips 2322 711 61472 40-34700-101 1
R299 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
R300 100 Ohm 5% 0,125W 1206 Philips 2322 711 61101 40-21000-101 1
Page 15 of 21
