18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
C458 3,3n 10% 100V X7R 0805
NiSn
Philips 08052R332K0B200 46-33300-281 1
C459 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C460 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C461 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C462 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C463 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C464 1,8n 5% 50V NPO 0805
NiSn
Phycomp 0805CG182J9B200 46-31800-080 1
C465 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
C466 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C467 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C468 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C469 150p 5% 50V NPO 0805
NiSn
Philips 0805CG151J9BB- 46-21500-081 1
C470 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C471 47p 5% 50V NPO 0805
NiSn
Philips 0805CG470J9B200 46-14700-080 1
C472 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C473 10u 20% 25V 6032 TA
Cap
AVX TAJC106M025R 47-11002-520 1
C474 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C475 22p 5% 50V NPO 0805
NiSn
Philips 0805CG220J9B200 46-12200-081 1
C476 1n 5% 50V NPO 0805
NiSn
Philips 0805CG102J9BB- 46-31000-082 1
D101 Diode,PIN 150V 1ohm@10mA
700nsTrr SC79
Infineon BAR67-02V BAR67-02V 1
D102 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D103 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D104 Diode, Pin atten, dual com K
SOT23
HP HSMP-3814 HSMP-3814 1
D201 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D205 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D206 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D207 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D210 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
Page 8 of 21
