18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
L413 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L414 Ind, 680nH 5% 3225 TDK NL322522T-R68J 43-80068-001 1
L415 Ind, 180nH 5% 3225 TDK NL322522T-R18J 43-80018-001 1
L416 Ind, 680nH 5% 3225 TDK NL322522T-R68J 43-80068-001 1
L417 Ind, 47uH 5% 3225 TDK NL322522T-470J 43-81470-001 1
P1 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P201 Header (P) 4way 1row Molex 22-03-2041 60-00041-100 1
R101 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R102 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R103 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R104 8,2k Ohm 5% 0,1W 0805 Philips 2322 730 61822 40-38200-111 1
R105 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R106 68 Ohm 5% 0,1W 0805 Philips 2322 730 61689 40-16800-111 1
R107 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R108 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R109 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R110 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R111 150 Ohm 5% 0,1W 0805 Philips 2322 730 61151 40-21500-111 1
R112 150 Ohm 5% 0,1W 0805 Philips 2322 730 61151 40-21500-111 1
R113 180 Ohm 5% 0,1W 0805 Philips 2322 730 61181 40-21800-111 1
R114 22 Ohm 5% 0,1W 0805 Philips 2322 730 61229 40-12200-111 1
R115 22 Ohm 5% 0,1W 0805 Philips 2322 730 61229 40-12200-111 1
R116 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R117 220 Ohm 5% 0,1W 0805 Philips 2322 730 61221 40-22200-111 1
R118 68k Ohm 5% 0,1W 0805 Philips 2322 730 61683 40-46800-111 1
R119 82k Ohm 5% 0,1W 0805 Philips 2322 730 61823 40-48200-111 1
R120 82k Ohm 5% 0,1W 0805 Philips 2322 730 61823 40-48200-111 1
R121 3,9k Ohm 5% 0,1W 0805 Philips 2322 730 61392 40-33900-111 1
R122 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R123 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R124 82k Ohm 5% 0,1W 0805 Philips 2322 730 61823 40-48200-111 1
Page 11 of 21
