Codan NGT 2012 RF User Manual

18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
R208 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R209 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R210 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R211 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R212 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R213 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R214 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R215 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R216 10 Ohm 5% 0,06W 0603 Philips 2322 702 60109 40-11000-121 1
R217 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R218 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R219 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R220 68k Ohm 5% 0,1W 0805 Philips 2322 730 61683 40-46800-111 1
R221 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R222 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R223 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R224 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R225 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R226 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R227 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R228 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R229 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R230 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R231 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R232 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R233 6,8k Ohm 5% 0,1W 0805 Philips 2322 730 61682 40-36800-111 1
R234 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R235 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R236 5,6k Ohm 5% 0,1W 0805 Philips 2322 730 61562 40-35600-111 1
R237 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
Page 13 of 21
