Codan NGT 2012 RF User Manual

18 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05889-001 - RF/IF PCB
BOM Revision
Date Valid On
R268 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R269 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R270 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R271 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R272 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R273 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R274 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R275 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R276 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R277 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R278 0 Ohm Jumper 0805 Philips 2322 730 91002 40-00001-111 1
R279 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R280 560k Ohm 5% 0,1W 0805 Philips 2322 730 61564 40-55600-111 1
R281 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R282 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R283 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
R284 1,5M Ohm 5% 0,1W 0805 Yageo RC0805JR-071M5L 40-61500-111 1
R285 180k Ohm 5% 0,1W 0805 Philips 2322 730 61184 40-51800-111 1
R286 10M Ohm 1% 0,1W 0805 Philips 2322 734 61006 40-71000-115 1
R287 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R289 8,2k Ohm 5% 0,1W 0805 Philips 2322 730 61822 40-38200-111 1
R290 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R291 1,2k Ohm 5% 0,1W 0805 Philips 2322 730 61122 40-31200-111 1
R292 1,8k Ohm 5% 0,1W 0805 Philips 2322 730 61182 40-31800-111 1
R293 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R294 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R295 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R296 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R297 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R298 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
Page 15 of 21
