Codan NGT 2012 RF User Manual

03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06461-001 - PA c/w Heatsink PCB
BOM Revision
Date Valid On
D208 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D209 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
IC200 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC201 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
J200 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
K200 Relay, 1C 12V 16A 340
Ohm
Eberle 042901 62 0100 64-31125-234 1
L200 Choke, EMI/EMC 0A DC
>10MHz 0805
Taiyo Yuden BK 2125 HS 330-T 43-90004 1
L201 Choke, EMI/EMC 0A DC
>10MHz 0805
Taiyo Yuden BK 2125 HS 330-T 43-90004 1
L202 Ind, 1,8uH 5% 2520 Vishay IMC1008-1800NH-5 43-80180-001 1
L203 Ind, 100nH 20% 3225 TOKO 380NB-R10M 43-80010-000 1
L204 Ind, 2,2uH 10% 3225 TOKO 380LB-2R2K 43-80220-001 1
L205 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L206 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L207 Ind, PA DC feed or/wh/or Fetronics 44-70457 44-70457 1
P200 Header (P) 16way 2row Boxed
SMD 2,54mm
Neltron 2316SMD-16G 60-00160-003 1
R200 47 Ohm 5% 0,1W 0805 Philips 2322 730 61479 40-14700-111 1
R201 47 Ohm 5% 0,1W 0805 Philips 2322 730 61479 40-14700-111 1
R202 56 Ohm 5% 0,1W 0805 Philips 2322 730 61569 40-15600-111 1
R203 330 Ohm 5% 0,1W 0805 Philips 2322 730 61331 40-23300-111 1
R204 330 Ohm 5% 0,1W 0805 Philips 2322 730 61331 40-23300-111 1
R205 Pot,100 Lin MG Trim SMD Bourns 3314 J-1-101 42-21004-000 1
R206 27 Ohm 5% 0,1W 0805 Philips 2322 730 61279 40-12700-111 1
R207 10 Ohm 5% 0,1W 0805 Philips 2322 730 61109 40-11000-111 1
R208 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R209 3,9k Ohm 5% 0,1W 0805 Philips 2322 730 61392 40-33900-111 1
R210 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R211 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R212 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R213 680 Ohm 5% 0,1W 0805 Philips 2322 730 61681 40-26800-111 1
R214 680 Ohm 5% 0,1W 0805 Philips 2322 730 61681 40-26800-111 1
R215 390 Ohm 5% 0,1W 0805 Philips 2322 730 61391 40-23900-111 1
