09 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05910-001 - Filter & Control PCB
BOM Revision
Date Valid On
R71 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R72 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R73 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R74 10k Ohm 1% 0,06W 0603 Phycomp 2322 704 61003 40-41000-125 1
R75 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R76 10k Ohm 1% 0,06W 0603 Phycomp 2322 704 61003 40-41000-125 1
R77 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R78 10k Ohm 1% 0,06W 0603 Phycomp 2322 704 61003 40-41000-125 1
R79 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R80 10k Ohm 1% 0,06W 0603 Phycomp 2322 704 61003 40-41000-125 1
R81 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R82 10k Ohm 1% 0,06W 0603 Phycomp 2322 704 61003 40-41000-125 1
R83 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R84 20k Ohm 1% 0,06W 0603 Phycomp 2322 704 62003 40-42000-125 1
R85 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R86 100 Ohm 5% 1,0W 2512 Phycomp 2322 762 60101 40-21000-141 1
R87 180 Ohm 5% 1,0W 2512 Phycomp 2322 762 60181 40-21800-141 1
R88 470k Ohm 5% 0,1W 0805 Philips 2322 730 61474 40-54700-111 1
R89 3,3M Ohm 5% 0,1W 0805 Philips 2322 730 61335 40-63300-111 1
R90 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R91 220k Ohm 5% 0,1W 0805 Philips 2322 730 61224 40-52200-111 1
R92 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R93 1M Ohm 5% 0,1W 0805 Philips 2322 730 61105 40-61000-111 1
T1 Txfr, RF or Fetronics 44-80021 44-80021 1
V1 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V2 Transistor, PNP Si TO252 Motorola MJD32C MJD32C 1
V3 Transistor, NPN Si SOT23 Philips BC817 BC817 1
V4 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V5 Transistor, PNP Si SOT23 Philips BC858 BC858 1
