10 -- Production
27.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05511-001 - PA Assy c/w Heatsink
BOM Revision
Date Valid On
C217 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C218 22p 5% 50V NPO 1206
NiSn
Philips 1206CG220J9BB- 46-12200-080 1
C219 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C220 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C221 10n 10% 100V X7R 1206
NiSn
Philips 12062R103K0BB- 46-41000-280 1
C222 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
C223 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C224 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C225 330p 5% 500V NPO 1210
NiSn
Philips 1210CG311GBB- 46-23300-082 1
C226 47p 5% 50V NPO 1206
NiSn
Philips 1206CG470J9BB- 46-14700-081 1
C227 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C228 100u 25V Ax EL Cap Elna RB 48-21002-551 1
C229 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C230 100n 10% 50V X7R 1206
NiSn
Philips 12062R104K9BB- 46-51000-281 1
C231 470n 10% 63V PE Cap Philips 2222 370 18474 46-54700-521 1
C232 33n 10% 100V X7R 1206
NiSn
Philips 12062R333K0BB- 46-43300-280 1
C233 100p 5% 50V NPO 1206
NiSn
Philips 1206CG101J9BB- 46-21000-080 1
D200 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D201 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D202 Diode, Schottky 70V 70mA
SOT23
Siemens BAS70 BAS70 1
D203 Diode, Zener 15V 5% 0,2W
SOT23
Philips BZX84-C15 BZX84C15 1
D204 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D205 Diode, Si 400V 1A Fairchild 1N4004 1N4004 1
IC200 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC201 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC202 Amp, Oper Dual CMOS
SOIC8
National Semiconduct LMC662CM XA-00662-700 1
J200 Socket, Coax Mini Low Prof
Fixed
Taiko Denki TMP-J02X-A1 60-19390-002 1
K200 Relay, 1C 12V 16A 340
Ohm
Eberle 042901 62 0100 64-31125-234 1
L202 Ind, 1uH 10% 3028 Coilcraft 1008CS-102XKBC 43-80100-000 1
L205 Ind, PA DC feed or/wh/or Fetronics 44-70457 44-70457 1
Page 2 of 5
