03 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-06261-001 - Audio Interconnect & Data I/O PCB
BOM Revision
Date Valid On
C114 560p 5% 50V NPO 0603
NiSn
Philips 0603CG561J9BB00 46-25600-080 1
C115 10n 10% 100V X7R 0805
NiSn
Philips 08052R103K0B200 46-41000-281 1
C116 10p 5% 50V NPO 0805
NiSn
Philips 0805CG100J9B200 46-11000-081 1
D1 Diode, 400V 1A SMA On Semiconductor MRA4004T3 MRA4004T3 1
D2 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D3 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D4 Diode, Zener 5,6V 5% 0,2W
SOT23
Philips BZX84-C5V6 BZX84C5V6 1
D5 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D6 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D7 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D8 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D9 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D10 Diode, Schottky SOT23 Philips BAT54 BAT54 1
D11 TVS, Bidirec 15V wkg SMB SGS Thomson SMBJ15CA-TR SMBJ15CA-TR 1
D12 TVS, Bidirec 15V wkg SMB SGS Thomson SMBJ15CA-TR SMBJ15CA-TR 1
D13 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
F1 0,1 Ohm nom 1,6A@20'C
16Vwkg SMD
Raychem SMDH160 41-10010-000 1
F2 0,1 Ohm nom 1,6A@20'C
16Vwkg SMD
Raychem SMDH160 41-10010-000 1
G1 Cell, Lithium 3V, 35mAh PCB
Mtg
National Semiconduct BR1225-1VD 65-71000-002 1
H1 LED, Tricolour T-1 3/4
Diffused
Liteon LTL-52RG 65-61110-901 1
IC1 Amp, Audio Power 2x11w
SIL9P
Philips TDA1519C TDA1519C 1
IC2 Amp, Operational Dual
SOIC8
National Semiconduct LM358M XA-00358-700 1
IC3 DTMF Tone Generator
SOIC8
Philips PCD3312CT-118 XE-03312-700 1
IC4 Pot, Digital 10k 256 Position
SOIC16
Analog Devices AD5242BR10 YN-05242-700 1
IC5 Mux/Demux, Analog, Triple 2ch
SOIC16
Philips HEF4053BT-653 YH-40053-701 1
IC6 Tcvr, CAN bus
SOIC8
Philips PCA82C250T YI-82250-700 1
IC7 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC9 Micro prgmd, 2011 Audio I/O Codan 90-20625-001 90-20625-001 1
IC10 Clock/Calendar/RAM IIC Bus
SOIC8
SGS Thomson MK41T56S00TR YK-04156-700 1
IC11 Tcvr, RS232 5Tx / 3Rx ESD
Prot TSSOP24
Sipex SP3249ECY YI-03249-700 1
IC12 Comparator, Quad O/C Output
SOIC14
National Semiconduct LM339M XD-00339-700 1
Page 5 of 12
