03 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06261-001 - Audio Interconnect & Data I/O PCB
BOM Revision
Date Valid On
R126 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R127 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R128 560 Ohm 5% 0,1W 0805 Philips 2322 730 61561 40-25600-111 1
R129 330 Ohm 5% 0,1W 0805 Philips 2322 730 61331 40-23300-111 1
R130 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R131 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R132 33k Ohm 5% 0,1W 0805 Philips 2322 730 61333 40-43300-111 1
R133 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R134 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R135 100 Ohm 5% 0,1W 0805 Philips 2322 730 61101 40-21000-111 1
R136 10 Ohm 5% 0,1W 0805 Philips 2322 730 61109 40-11000-111 1
R137 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R138 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R139 6,8k Ohm 5% 0,1W 0805 Philips 2322 730 61682 40-36800-111 1
R140 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R141 18k Ohm 5% 0,1W 0805 Philips 2322 730 61183 40-41800-111 1
R142 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R143 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R146 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R147 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R148 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R149 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R150 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
R151 100k Ohm 5% 0,1W 0805 Philips 2322 730 61104 40-51000-111 1
T1 Txfr, Line isolation SMD Etal P2781 43-30002 1
T2 Txfr, Line isolation SMD Etal P2781 43-30002 1
V1 Transistor, PNP Si SOT23 Philips BC857 BC857 1
V2 Diode, Zener 6,8V 5% 0,2W
SOT23
Philips BZX84C6V8 BZX84C6V8 1
V3 Transistor, NPN Si SOT23 Philips BC847 BC847 1
V4 Transistor, NPN Si SOT23 Philips BC847 BC847 1
Page 11 of 12
