Codan NGT 2012 RF User Manual

02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-06260-001 - Appn Proc PCB, Handset & Data I/F
BOM Revision
Date Valid On
C54 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C55 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C56 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C57 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C58 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C59 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C60 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C61 100n 10% 16V X7R 0603
NiSn
Vitramon VJ0603Y104KXJT 46-51000-283 1
C62 Not Fitted Codan **-00000-001 99-00000-001 1
C63 Not Fitted Codan **-00000-001 99-00000-001 1
C64 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C65 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C66 10u 20% 20V 3528 TA
Cap
AVX TAJB106M020R 47-11002-000 1
C67 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C68 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C69 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C70 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C71 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C72 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C73 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C74 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C75 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C76 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C77 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C78 100p 5% 50V NPO 0603
NiSn
Philips 0603CG101J9B200 46-21000-083 1
C79 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C80 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
C81 33n 10% 25V X7R 0603
NiSn
Vitramon VJ0603Y333KXXT 46-43300-282 1
D1 Diode, Schottky 40V 1A
SMA
Taiwan Semiconductor SS14 MBRA140T3 1
D2 Diode, Schottky SOT23 Philips BAT54 BAT54 1
Page 3 of 8
