Codan NGT 2012 RF User Manual

05 -- Production
27.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05267-001 - Desk Console PCB
BOM Revision
Date Valid On
P2 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
R1 Not Fitted Codan **-00000-001 99-00000-001 1
R2 Not Fitted Codan **-00000-001 99-00000-001 1
R3 Not Fitted Codan **-00000-001 99-00000-001 1
R4 Not Fitted Codan **-00000-001 99-00000-001 1
R5 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R6 330k Ohm 5% 0,1W 0805 Philips 2322 730 61334 40-53300-111 1
R7 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R8 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R9 2,2k Ohm 5% 0,1W 0805 Philips 2322 730 61222 40-32200-111 1
R10 1k Ohm 5% 0,1W 0805 Philips 2322-730-61102 40-31000-111 1
R11 22k Ohm 5% 0,1W 0805 Philips 2322 730 61223 40-42200-111 1
R12 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
R13 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R14 47k Ohm 5% 0,1W 0805 Philips 2322 730 61473 40-44700-111 1
R15 330k Ohm 5% 0,1W 0805 Philips 2322 730 61334 40-53300-111 1
V1 Not Fitted Codan **-00000-001 99-00000-001 1
V2 Not Fitted Codan **-00000-001 99-00000-001 1
V3 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V4 MOSFET, N Chan Enhance
SOT23
Philips BST82 BST82 1
Page 2 of 2

Codan NGT 2012 RF Specifications

General

Brand	Codan
Model	NGT 2012 RF
Category	Transceiver
Language	English
