Codan NGT 2012 RF User Manual

01 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05976-001 - 500/1000W HF Filter PCB
BOM Revision
Date Valid On
Capacitors, 150pF +/-2% Braemac 23-40003 TO 10-00936 23-40003 1
Capacitors, 720pF +/-2% Braemac 23-40002 TO 10-00936 23-40002 1
TP,500W/1kW Filter Alignment 10-00926 1
500/1000W Filters 04-03415 1
Capacitors, 860pF +/-2% Braemac 23-40011 TP 10-00936 23-40011 1
Capacitors, 800pF +/-2% Braemac 23-40012 TO 10-00936 23-40012 1
* 500/1000W HF Filter PCB 08-05976 1
1 PCB, 500/1000W HF PA Filter IMP 07-01977-02 07-01977-02 1
2 Rivet, Tinned Brass Chobert
4,0dx9,5
Avdel 01143-00516 33-40340-095 12
3 Stake, Terminal Autosplice 7-22461-5 61-40300-004 2
C101 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C102 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C103 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C104 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C201 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C202 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C203 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C204 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C301 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C302 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C303 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C304 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C401 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C402 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C403 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C404 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C421 56p 5% 2kV NPO CE
Cap
MMC HS15SJCH560J 46-15600-090 1
C501 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C502 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C503 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C504 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
C601 33n 20% 25V CE Cap Murata DD406SR333M25 46-43300-211 1
