Codan NGT 2012 RF User Manual

02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05978-001 - PSU 500/1000 W PA PCB
BOM Revision
Date Valid On
R112 Pot,100 Lin MG Trim SMD Bourns 3314 J-1-101 42-21004-000 1
R113 3,3k Ohm 5% 0,1W 0805 Philips 2322 730 61332 40-33300-111 1
R114 1,5k Ohm 1% 0,1W 0805 Philips 2322 734 61502 40-31500-115 1
R115 68k Ohm 5% 0,1W 0805 Philips 2322 730 61683 40-46800-111 1
R116 11k Ohm 1% 0,1W 0805 Philips 2322 734 61103 40-41100-115 1
R117 Pot,10k Lin MG Trim SMD Bourns 3314 J-1-103 42-41004-000 1
R118 220k Ohm 5% 0,1W 0805 Philips 2322 730 61224 40-52200-111 1
R119 68k Ohm 5% 0,1W 0805 Philips 2322 730 61683 40-46800-111 1
R120 4,7k Ohm 5% 0,1W 0805 Philips 2322 730 61472 40-34700-111 1
R121 10 Ohm 5% 0,125W 1206 Philips 2322 711 61109 40-11000-101 1
R122 15 Ohm 5% 0,125W 1206 Philips 2322 711 61159 40-11500-101 1
R124 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R125 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R126 0,015 Ohm 1% 1,0W 2512 Vishay WSL2512R0150FEA 40-00015-132 1
R127 220 Ohm 1% 0,1W 0805 Philips 2322 734 62201 40-22200-115 1
R128 2,2k Ohm 1% 0,1W 0805 Philips 2322 734 62202 40-32200-115 1
R129 680 Ohm 1% 0,1W 0805 Philips 2322 734 66801 40-26800-115 1
R140 4,7 Ohm 5% 0,125W 1206 Philips 2322 711 61478 40-04700-101 1
R141 10k Ohm 5% 0,1W 0805 Philips 2322-730-61103 40-41000-111 1
T1 Txfr, Pulse 2:1+1 200Vus 3kHz
-
3MHz
Oxford Electrical PT8 43-20000 1
TP2 Header (P) 2way 1row Molex 22-03-2021 60-00021-100 1
TP102 Header (P) 2way 1row Molex 22-03-2021 60-00021-100 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V2 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V3 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V4 Diode, Zener 30V 5% 0,2W
SOT23
Philips BZX84-C30 BZX84C30 1
V7 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V8 Transistor, PNP Si 250V 50mA
0,25W SOT23
Philips BF823 BF823 1
V9 Transistor, PNP Si 250V 50mA
0,25W SOT23
Philips BF823 BF823 1
V10 MOSFET, N Channel Enhance
SOT223
Philips BSP126 BSP126 1
