Codan NGT 2012 RF User Manual

07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05854-001 - NRI Micro-Controller PCB
BOM Revision
Date Valid On
C209 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C210 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C211 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C212 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C213 27p 5% 50V NPO 0805
NiSn
Philips 0805CG270J9B200 46-12700-080 1
C214 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
C215 33n 10% 50V X7R 0805
NiSn
Philips 08052R333K9BB00 46-43300-281 1
D101 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
D201 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D202 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D203 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
H201 LED, Tricolour T-1 3/4
Diffused
Liteon LTL-52RG 65-61110-901 1
H203 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
H204 LED, Green PLCC SMD Non
Diffused
Siemens LGT670-L 65-61110-507 1
IC101 EPLD prgmd, NRI Codan 90-20605-001 90-20605-001 1
IC102 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC103 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC104 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC105 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC106 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC107 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC108 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC109 Switch, Analog Quad Fast
SOIC16
Harris DG445DY YI-00445-700 1
IC110 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC111 Reg, Voltage +10V LVD 1A
TO263_3
National Semiconduct LM2940S-10 XB-02940-700 1
IC112 Reg, Voltage +5V 0,5A Switch
SOIC8
AVX LM2674M-5.0 XB-02674-700 1
IC201 DUART, CMOS
PLCC44
Philips SC26C92C1A YK-02692-900 1
IC202 Monitor, Micro
SOIC8
Dallas DS1232LPS-2 XD-01232-700 1
IC203 MicroC, 16 Bit CMOS
QFP20112
Hitachi HD6413003TF16 YP-83003-700 1
