Codan NGT 2012 RF User Manual

07 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05854-001 - NRI Micro-Controller PCB
BOM Revision
Date Valid On
R236 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R237 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R238 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R239 47 Ohm 5% 0,06W 0603 Philips 2322 702 60479 40-14700-121 1
R240 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R241 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R242 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R243 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R244 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R245 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R246 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
V101 Transistor, NPN Si SOT23 Philips BFR92A BFR92A 1
V201 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V202 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V203 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V204 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V205 Diode, Zener 3,3V 5% 0,2W
SOT23
Philips BZX84-C3V3 BZX84C3V3 1
Z201 Crystal, 16000 kHz uP
Grade
HY-Q QC49/SMD 65-90103 1
Z202 Crystal, 3686,4 kHz uP
Grade
HY-Q M/P QC49/SMD EBO1C 65-90101 1
Page 7 of 7
