05 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05855-001 - User Connect PCB, 3030
BOM Revision
Date Valid On
D104 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D105 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D106 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D107 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D108 Diode, Si High speed 75V
SOT23
Philips BAS16 BAS16 1
D109 Diode, Schottky 40V 3A
SMC
Motorola MBRS340T3 MBRS340T3 1
IC101 MOSFET, high side switch 4A
SOT426
Philips BUK207-50Y BUK207-50Y 1
IC102 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
IC103 Tcvr, RS232 6Tx / 10Rx ESD
PROT TSSOP38
Maxim MAX3209ECUU YI-03209-700 1
IC105 Reg, Voltage +5V 0,1A
SOIC8
National Semiconduct LM78L05ACM XB-07805-700 1
J101 Plug, 2way 2,5mm DC Power Marushin MJ-180LE 60-00020-003 1
J102 Plug, 2way 2,5mm DC Power Marushin MJ-180LE 60-00020-003 1
K101 Relay, 2C 12V 2A SMD 1028
Ohm
Matsushita TQ2SL-12V 64-21225-310 1
L101 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L102 Choke, Common Mode (Data)
SMD
Taiyo Yuden CM04RC04 43-82470-000 1
L103 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L104 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L105 Ind, Common Mode 5.5A Taiyo Yuden CMO8RA20 43-80001 1
L106 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
L107 Choke, EMI/EMC 0A DC
>1MHz 4516
Taiyo Yuden FCFBMJ 4516 HS 110-
T
43-90003 1
P101 Plug, 8way fixed w/round nut Nisshin NS1508L 60-00080-005 1
P102 Plug, 8way fixed w/round nut Nisshin NS1508L 60-00080-005 1
P104 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P105 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
P106 Header (P) 26way 2row Boxed
Fix
Thomas & Betts 609-2627 60-00260-000 1
P107 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
P108 Plug, 9way PCB Fixed ITT-Cannon DEPF-9P-Y4 60-00090-090 1
P109 Plug, 25way D Straight PCB
Fixed
McMurdo DB-25P-OL2 60-00250-093 1
R101 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
R102 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R103 4,7k Ohm 5% 0,06W 0603 Philips 2322 702 60472 40-34700-121 1
Page 3 of 5
