04 -- Production
28.09.2006
Ref Descri
tion Manufacturer Manufacturer's P/N Codan P/N Qt
08-05860-001 - DSP Modem PCB, 3012
BOM Revision
Date Valid On
IC102 Monitor, Micro
SOIC8
Dallas DS1232LPS-2 XD-01232-700 1
IC103 Reg, Voltage +5V 0,5A Switch
SOIC8
AVX LM2674M-5.0 XB-02674-700 1
IC104 300v, Voltage, Switching
SOIC8
Linear Tech LT1054CS8 XB-01054-700 1
IC105 Reg, Voltage -5V 0,1A
SOIC8
National Semiconduct LM79L05ACM XB-07905-700 1
IC106 EPLD prgmd, 3012 Codan 90-20607-001 90-20607-001 1
IC107 DUART, FIFO & parallel port
SQFP12x12-80
Texas Instruments TL16C552APN YK-16552-901 1
IC108 Voice-Band ADC & DAC 14Bit
PLCC28
Texas Instruments TLC32044EFN YN-32044-900 1
IC109 Amp, Op Dual Fast
SOIC8
Texas Instruments TLE2082CD XA-02082-700 1
IC201 RAM, CMOS 256k x 16 Bit
20nS TSOP2-44
Cypress CY7C1041B-20ZC YM-71041-700 1
IC202 EPROM prgmd, 3012 D0-D15 Codan 90-20606-101 90-20606-101 1
IC203 RAM, CMOS 256k x 16 Bit
20nS TSOP2-44
Cypress CY7C1041B-20ZC YM-71041-700 1
IC204 EPROM prgmd, 3012 D16-D31 Codan 90-20606-201 90-20606-201 1
IC205 EEPROM, CMOS 256x8 Bit IIC
Bus SOIC8
SGS Thomson ST24C02A M1 YM-02402-700 1
IC206 Shift Register, 8 Bit T/state
SOIC16
Motorola MC74HC595D YH-74595-700 1
IC207 Shift Register, 8 Bit T/state
SOIC16
Motorola MC74HC595D YH-74595-700 1
L101 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L102 Ind, 100uH 1,2A SMPS
SMD
Epcos B82476-A1104-M 43-82100-003 1
L103 Ind, 10uH 10% 4532 Taiyo Yuden LEM 4532T100K 43-81100-000 1
L104 Ind, 1,5uH 10% 3225 TOKO 380LB-1R5K 43-80150-000 1
P103 Header (P) 4way 2mm Latch
Fixed
AMP 173981-4 60-00040-352 1
P105 Header (P) 16way 2row Boxed Thomas & Betts 609-1627 60-00160-000 1
P106 Header (P) 10way 2mm Latch
Fixed
AMP 1-173981-0 60-00100-351 1
R101 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R102 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R103 22k Ohm 5% 0,06W 0603 Philips 2322 702 60223 40-42200-121 1
R104 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
R105 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R106 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R107 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R108 33k Ohm 5% 0,06W 0603 Philips 2322 702 60333 40-43300-121 1
R109 10k Ohm 5% 0,06W 0603 Philips 2322 702 60103 40-41000-121 1
