02 -- Production
28.09.2006
Ref Descri
p
tion Manufacturer Manufacturer's P/N Codan P/N Qt
y
08-05861-001 - User Connector PCB, 3012
BOM Revision
Date Valid On
R28 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R29 100 Ohm 5% 0,06W 0603 Philips 2322 702 60101 40-21000-121 1
R30 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R31 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R32 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R33 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R34 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R35 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R36 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R37 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R38 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R39 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R40 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
R41 1k Ohm 5% 0,06W 0603 Philips 2322 702 60102 40-31000-121 1
V1 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V2 Transistor, PNP Si SOT23 Philips BC858 BC858 1
V3 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V4 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V5 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V6 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V7 Transistor, NPN Si SOT23 Philips BC848 BC848 1
V14 Optocoupler, Quad
SOT223/10
Infineon SFH6943-4T SFH6943 1
V15 Optocoupler, Quad
SOT223/10
Infineon SFH6943-4T SFH6943 1
Page 4 of 4
