3-14 DS10 Console Reference
Figure 3–10 Advanced PCI Information
Display System Configuration F1=Help
Advanced PCI Information
➊ ➋ ➌
Bus Number=0, Device Number=1, Function Number=0
➍
Configuration Space:
Register Hex offset Hex
Vendor ID 00 1090
Device ID 02 5237
Command 04 0280
Status 06 0280
Revision ID 08 03
Prog. I/F 09 10
Sub Class Code 0a 03
Class Code 0b 0c
Cache Line Size 0c 08
Latency Timer 0d 20
Header Type 0e 00
BIST 0f 00
Base Address 0 10 03884000
ENTER =Continue
➊
Bus number — The virtual PCI bus number.
➋
Device number — The PCI bus device number.
➌
Function number — Represents the number assigned to a particular
function on a multifunction device. For example, a combination
Ethernet/SCSI controller would be listed twice, with the first function
listed as 0 and the other as 1.
➍
Configuration header space — Displays the information in the selected
device’s PCI configuration space.
Press ESC to return to the list of PCI devices.
