3-18 DS10 Console Reference
3.3.7 Integrated Peripherals
Figure 3–13 Integrated Peripherals
Dis
la
S
stem Confi
uration F1=Hel
Systemboard Configuration
Hard Disk Configuration
PCI Configuration
SCSI Configuration
ISA Configuration
Memory Configuration
Integrated Peripherals
Integrated Peripheral State
➊ ➋ ➌ ➍
Serial 0: Enabled [ port 0x3f8, IRQ 4 ]
Serial 1: Enabled [ port 0x2f8, IRQ 3]
Parallel: Enabled [ port 0x3bc, IRQ 7]
Floppy Ctrl: Enabled [ port 0x3f0, IRQ 6, DMA2]
Kbd/Mouse: Enabled [ port 0x60, kbd IRQ 1, mouse IRQ 12]
Acer IDE Chnl 0: Enabled [ port 0x1f0, IRQ 14]
ESC =Exit
➊
Device type — The physical device as it exists on the system board.
➋
MS-DOS name — Shows if the device is enabled, and if it is enabled,
the addressable MS-DOS name for the device.
➌
Port address — The physical memory location for data received into
the device, and sent from the device, respectively.
➍ Interrupt — The interrupt request line (IRQ) used by the device to get
the CPU’s attention.
