Compaq Deskpro EN Series of Personal Computers 9-5
Rear Side of Minitower Riser Board
Table 9-5
Rear Side of Riser Board
Item Description Item Description
P1 Power supply connector P10 Diskette drive connector
P5 Hood control, power switch, LEDs P20 Primary IDE connector
P7 CD audio connector P21 Secondary IDE connector
