Compaq Deskpro EN Series of Personal Computers 5-35
5.15.2 Matrox Millennium II Graphics Memory
1. Prepare the computer for disassembly (Section 5.4).
2. Remove the system unit cover (Section 5.6).
3. Disconnect and raise the expansion board cage (Section 5.12.1).
4. Pull the system board out of the chassis to get clear access to the graphics board, then remove
the AGP graphics board (Section 5.15.1).
5. Place the graphics board on a flat, static dissipative surface and install the upgrade memory
module.
6. Ensure that all pins on the module are properly aligned to avoid damaging them.
✎
If you are removing a memory module, rock the module gently from side to side
while pulling it up.
Installing the Graphic Memory Module on the Matrox Millennium II AGP Graphics Board
To install the graphics board, reverse the above procedure.
✎
The resolution must be changed via the Control Panel to take advantage of the
additional display modes.
