6-8 Minitower Removal and Replacement
6.7 Front Bezel Assembly
6.7.1 Front Bezel Removal
1. Prepare the computer for disassembly (Section 6.3).
CAUTION:
When the computer is plugged into an AC power source, there is always voltage applied to the
system board. You must disconnect the power cord from the power source before opening the computer
to prevent system board or component damage.
2. Remove the access panel (Section 6.6).
3. Press on the two tabs on the inside of the front bezel (as indicated by the arrows on the chassis),
then pivot the bezel away from the computer before disengaging it from the chassis.
Removing the Front Bezel
To install the front bezel, reverse the removal procedure.
