5-34 Desktop Removal and Replacement
5.15 Graphics Solutions
5.15.1 AGP Graphics Board Removal
1. Prepare the computer for disassembly (Section 5.4).
CAUTION:
When the computer is plugged into an AC power source, there is always voltage applied to the
system board. You must disconnect the power cord from the power source before opening the computer
to prevent system board or component damage.
2. Remove the system unit cover (Section 5.6).
3. Remove the screw that secures the AGP board to the system board tray, then remove the AGP
board.
Removing the AGP Graphics Board
To install the AGP board, reverse the removal procedure.
