Compaq Deskpro EN Series of Personal Computers 6-7
6.6 Access Panel Removal
1. Prepare the computer for disassembly (Section 6.3).
CAUTION:
When the computer is plugged into an AC power source, there is always voltage applied to the
system board. You must disconnect the power cord from the power source before opening the computer
to prevent system board or component damage.
2. Remove the three screws that secure the access panel to the chassis.
3. Press in at the topmost screw area to release the manual catch; then, slide the access panel back
about 1-inch (2.5 -cm).
4. Rotate the top of the access panel away from the chassis; then, pull it up and off the unit.
Removing the Access Panel
To replace the access panel, reverse the removal procedure.
