5-6 Desktop Removal and Replacement
5.6 System Unit Cover Removal
1. Prepare the computer for disassembly (Section 5.4).
CAUTION:
When the computer is plugged into an AC power source, there is always voltage applied to the
system board. You must disconnect the power cord from the power source before opening the computer
to prevent system board or component damage.
2. Press in the quick release cover latch on each side of the front bezel to release the system unit
cover.
3. Slide the cover forward about 1-inch (2.5-cm); then, lift it up and off the unit.
Removing the System Unit Cover
To replace the cover, reverse the removal procedure.
CAUTION:
Always face the front of the chassis when replacing the system unit cover to prevent
damaging the diskette drive eject button.
