12 - Introduction DeviceMaster Installation and Configuration Guide: 2000594 Rev. F
Connectivity Requirements
Connectivity Requirements
An Ethernet connection: either to an Ethernet hub, switch, or router; or to a Network Interface Card (NIC) in
the host system using a standard Ethernet cable.
Device Driver
Linux
Install if you want tty ports. Refer to the Readme file
compressed in the Linux driver assembly for driver
configuration procedures.
Windows Server 2008
R2 through Windows
10
Install if you want COM ports.
Refer to the DeviceMaster Device Driver (NS-Link)
User Guide. for detailed information.
Bootloader
Bootloader
The operating system that runs on the DeviceMaster
hardware during the power on phase, which then loads
SocketServer.
Only update the Bootloader on your DeviceMaster if
advised by Technical Support or the download site
when checking for the latest SocketServer or device
driver version.
This
Guide
Any
You can check for the latest version of this Installation
and Configuration Guide.
Product Type Connected to Connector Name
DeviceMaster RTS 1-port panel mount Hub, switch, router, or NIC 10/100
ETHERNET
DM-2101 and DM-2201 (1-port DIN Rail) Hub, switch, router, or NIC 10/100
DM-2201 and DM-2302
(Formerly named the DeviceMaster RTS 2-port 1E models)
NIC
10/100
Hub, switch, or router
DM-2202 and DM-2402
(Formerly named the DeviceMaster RTS 2-port 2E models)
NIC
10/100 1E/2E
Hub, switch, or router
DeviceMaster RTS 4-port 2E panel mount
NIC
10/100 1E/2E
Hub, switch, or router
DM-2304 (4-port DIN Rail) Hub, switch, router, or NIC E1/E2
DeviceMaster RTS 4/8/16-port (external power supply)
NIC DOWN
Hub, switch, or router UP
DeviceMaster RTS 16/32RM (internal power supply) Hub, switch, router, or NIC 10/100
NETWORK
DeviceMaster PRO 8/16-port
NIC DOWN
Hub, switch, or router UP
DeviceMaster Serial Hub 8-port
NIC DOWN
Hub, switch, or router UP
DeviceMaster Serial Hub 16-port Hub, switch, router, or NIC 10/100 NETWORK
Software Description/Documentation File
