DeviceMaster Installation and Configuration Guide: 2000594 Rev. F External Power Supply Specifications - 145
External Power Supply Specifications
8-Port Power Supply
The following table provides the specifications for the Comtrol-supplied
power supply for the DeviceMaster 8-port.
The following table provides the specifications, if you intend on purchasing
your own power supply.
16-Port Power Supplies
The following table provides the specifications for the Comtrol-supplied power
supply for the DeviceMaster 16-port models.
Note: The DeviceMaster Serial Hub and DeviceMaster PRO, and DeviceMaster RTS (16-port and 32-port
models with a single Ethernet port) have an internal power supplies.
The following tables provide the specifications, if you intend on purchasing your own power supply for your
DeviceMaster RTS.
Comtrol Power Supply: 8-Port
Input line frequency
Input line voltage
Output voltage
Output current
47 - 63 Hz
90 - 260 VAC
24VDC
500 mA @ 24VDC
External Power Supply: 8-Port
Output voltage†
Current†
Power
9-30VDC
290 mA (Min) @ 24VDC
6.96 W
† Any power supply that meets current consumption, voltage,
power, and connector pin outs requirements can be used.
Comtrol Power Supply: 16-Port Models
Input line frequency
Input line voltage
Output voltage
Output current
47 - 63 Hz
90 - 260 VAC
24VDC
500 mA @ 24VDC
Note: The DeviceMaster RTS 16-port and 32-port models with
a single Ethernet port have internal power supplies.
External Power Supply: 16-Port
DeviceMaster RTS
Input line frequency N/A
Input line voltage N/A
Output voltage† 9-30VDC
Output current† 490 mA (Min) @ 24VDC
Power 11.76W
† Any power supply that meets current consumption, voltage, power, and
connector pin outs requirements can be used.
+VDC
V Return - GND
Shield GND
Housing Molex P/N:
39-01-4030
Pins Molex P/N:
44485-1211
+VDC
V Return - GND
Shield GND
Housing Molex P/N:
39-01-4030
Pins Molex P/N:
44485-1211
