Accessing Socket Configuration
Accessing Socket Configuration
There are several ways to access the socket configuration pages. Use the method that fits your environment
best.
• Web Browser
• PortVision DX
Web Browser
To access the socket configuration web interface for the DeviceMaster, follow this procedure.
1. Start your web browser.
2. Enter the IP address of the DeviceMaster in the URL field.
Note: If you do not know the IP address, you can view and highlight the IP address in PortVision DX and
click the Webpage button.
3. If necessary, enter admin as the username, your password, and then click the Login button.
4. Click the Port menu.
5. Click the port number that you want to configure socket port settings (serial, TCP connection
configuration, and UDP connection configuration).
Note: Refer to the web page Help system, if you need information about configuring sockets or serial tunneling,
which contains detailed configuration procedures and descriptions for all fields. See
Web Page Help
System on Page 62 for information about downloading the help file separately.
6. After changing the appropriate settings for your environment, click Save.
7. Click the Network tab to access the following pages if you need to configure additional settings:
• Configuration page to change the network settings.
• Password page to configure a password for the DeviceMaster.
• Security page to enable DeviceMaster security.
• Keys/Certs page to configure security certificates and keys.
• Email page to configure email notification services.
• RFC1006 page to configure RFC1006 settings.
PortVision DX
There are several ways to access the socket configuration page for the DeviceMaster using PortVision DX.
1. If necessary, start PortVision DX, right-click the DeviceMaster that you want to configure, and click
Webpage.
2. Follow Steps 3 through 7 from the previous procedure above (Web Browser).
